Xerox Phaser 7100 Service Manual

Parts List
Xerox Internal Use Only Phaser 7100 Service Manual 5-21
Parts List 3.1 Bypass Tray
Item Description Part Number
1. Bypass Tray Strap
2. Bypass Tray Frame Assembly (with 3-6, 8) (REP 3.1 Bypass Tray
Frame Assembly on page 4-69)
3. Turn Swing Chute
4. Swing Chute Spring
5. Tray Pinch Turn Spring
6. Tray Pinch Turn Roller
7. Bypass Tray F Earth Plate
8. Separator Retard Holder Assembly (REP 3.2 Separator Retard
Holder Assembly on page 4-70)
604K76880
9. Bypass Tray Cover Assembly (with 14-16) (REP 3.3 Bypass Tray
Cover Assembly/ Exit 1 Cover/ Exit 2 Cover on page 4-71)
848K33510
10. Left Pin
11. Left Bypass Tray Cover Lock (REP 3.4 Left/ Right Bypass Tray Cover
Lock on page 4-72)
803E04600
12. Right Bypass Tray Cover Lock (REP 3.4 Left/ Right Bypass Tray
Cover Lock on page 4-72)
803E04610
13. Right Pin
14. Exit 1 Cover
15. Exit 2 Cover
16. Bypass Tray Cover
17. -----
18. -----
19. -----
20. Bypass Tray Assembly (REP 3.5 Bypass Tray Assembly on
page 4-73)
050K69881

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
