Xerox Phaser 7100

Parts List
Xerox Internal Use Only Phaser 7100 Service Manual 5-23
Parts List 4.1 Front Frame (1 of 4)
Item Description Part Number
1. Front Arm Cap
2. Base Bracket Assembly
3. Damper Spring
4. Screw (M3 x 6B)
5. Rail Bracket Assembly
6. Front Frame Assembly Kit (same with PL 4.2 w/o 19-23) (REP 4.1
Front Frame Assembly on page 4-74)
7. DRW Fuser Harness Assembly (110V) (REP 4.2 DRW Fuser Harness
Assembly on page 4-80)
962K75021
DRW Fuser Harness Assembly (220V) 962K91000
8. Slide Bracket Assembly (with 9-11) (REP 4.3 Slide Bracket Assembly/
Slide Guide on page 4-87)
9. Slide Guide (REP 4.3 Slide Bracket Assembly/ Slide Guide on
page 4-87)
10. Slide Support Bracket
11. Spring Holder
12. Support Pin
