Xerox Phaser 7100 Service Manual

Parts List
Xerox Internal Use Only Phaser 7100 Service Manual 5-25
Parts List 4.2 Front Frame (2 of 4)
Item Description Part Number
1. Left Latch Lever (REP 4.4 Right/ Left Latch Lever, Latch Spring on
page 4-89)
2. Lever Shaft Assembly
3. Right Latch Lever (REP 4.4 Right/ Left Latch Lever, Latch Spring on
page 4-89)
4. Latch Spring (REP 4.4 Right/ Left Latch Lever, Latch Spring on
page 4-89)
5. Front Right Support Arm
6. Right Harness Cover
7. Right Arm Spring
8. AC Harness Cover
9. Front Frame Sub Assembly (with 10, 11, 18, PL 4.3.2-10, 12, 13, 15,
32) (REP 4.5 Front Frame Sub Assembly on page 4-91)
604K76861
10. Bypass Tray Feed Frame Assembly (all of PL 4.4) (REP 4.6 Bypass
Tray Feed Frame Assembly on page 4-97)
11. Front Harness Assembly
12. AC Cover
13. Front Left Support Arm
14. Fuser Motor Harness Cover
15. D Gear Cover
16. Fuser Drive Assembly (REP 4.7 Fuser Drive Assembly on page 4-99) 007K15890
17. Chute Assembly (REP 4.8 Chute Assembly on page 4-103)
18. Duplex Harness Assembly

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
