Xerox Phaser 7100 Service Manual

Parts List
Phaser 7100 Service Manual Xerox Internal Use Only5-30
Parts List 4.4 Front Frame (4 of 4)
Item Description Part Number
1. Bypass Tray Sensor Bracket Assembly (with 2-4) (REP 4.12 Bypass
Tray Sensor Bracket Assembly/ No Paper Sensor) on page 4-110)
068K69191
2. Bypass Tray Sensor Bracket
3. Bypass Tray No Paper Sensor (REP 4.12 Bypass Tray Sensor Bracket
Assembly/ No Paper Sensor) on page 4-110)
930W00113
4. Bypass Tray Sensor Harness Assembly
5. Bypass Tray Feed Frame
6. Bypass Tray Feed Bearing
7. Out Earth 2 Spring
8. Bypass Tray Arm
9. Spring
10. Right Follower
11. Left Follower
12. Bypass Tray Bottom Plate Assembly (with 20)
13. Left Bypass Tray Holder
14. Bypass Tray Feed Roller Assembly (REP 4.13 Bypass Tray Feed Roller
Assembly on page 4-112)
604K76890
15. Bypass Tray Cam
16. Bypass Tray Core Roller
17. Bypass Tray Shaft Assembly
18. Bypass Tray Feed Spring
19. Bypass Tray Feed Gear
20. Bypass Tray Pad
99. Bypass Tray Gear & Arm Kit (with 6-9, 18, 19) (REP 4.14 Bypass Tray
Feed Spring/ Feed Gear on page 4-113)
604K76870

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
