Xerox Phaser 7100 Service Manual

Parts List
Phaser 7100 Service Manual Xerox Internal Use Only5-32
Parts List 5.1 Registration
Item Description Part Number
1. Registration Chute Assembly (with 2-5) (REP 5.1 Registration Chute
Assembly on page 4-114)
054K41143
2. Registration Sensor Assembly (with 3, 4)
3. Registration Sensor (REP 5.2 Registration Sensor on page 4-116) 130E89381
4. Registration Sensor Plate
5. Chute Assembly
6. Turn Gear Assembly 17
7. Bearing
8. Bypass Tray Turn Roller (REP 5.3 Bypass Tray Turn Roller on
page 4-117)
9. Turn Clutch Assembly (REP 5.4 Turn Clutch Assembly on page 4-119)
10. Bypass Tray Idle Gear
11. Registration Clutch Assembly (REP 5.5 Registration Clutch Assembly
on page 4-120)
12. FRM Registration Bearing
13. Plain Washer
98. Bypass Tray Turn Roller Kit (with 6-10) 604K76910
99. Registration Clutch Kit (with 11-13) (REP 5.5 Registration Clutch
Assembly on page 4-120)
604K76900

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
