Xerox Phaser 7100 Service Manual

Parts List
Phaser 7100 Service Manual Xerox Internal Use Only5-34
Parts List 6.1 Xerographics
Item Description Part Number
1. Imaging Unit (Y/ M/ C) (REP 6.0 Imaging Unit (Y/ M/ C/ K) on
page 4-121)
See Supplies and Accessories
2. -----
3. -----
4. Imaging Unit (K) (REP 6.0 Imaging Unit (Y/ M/ C/ K) on page 4-121) See Supplies and Accessories
5. Right Imaging Unit Guide Assembly (with 6, 8, 9) (REP 6.1 Right
Imaging Unit Guide Assembly on page 4-123)
032K08280
6. Imaging Unit CRUM Connector Assembly (REP 6.2 Imaging Unit
CRUM Connector Assembly on page 4-124)
113K83410
7. -----
8. Right Imaging Unit Guide
9. Erase PWB Assembly
10. Right Latch Assembly (REP 6.3 Right Latch Assembly on page 4-126) 003K87760
11. Imaging Unit Guide Assembly (K) (with 6, 9, 12) (REP 6.4 (K)
Imaging Unit Guide Assembly on page 4-128)
032K06610
12. Imaging Unit Guide (K)
13. Left Imaging Unit Guide Assembly (REP 6.5 Left Imaging Unit Guide
Assembly on page 4-129)
14. CRUM X Harness Assembly (K)
15. CRUM X Harness Assembly (Y/ M/ C)

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
