Xerox Phaser 7100 Service Manual

Parts List
Phaser 7100 Service Manual Xerox Internal Use Only5-52
Parts List 12.4 Electrical (4 of 4)
Item Description Part Number
1. Image Processor PWB (ESS PWB) US/ 110V (REP 12.17 Image
Processor (I/P) PWB on page 4-228)
604K77272
2. 1 GB DDR2 DIMM (REP 12.18 Memory (Standard) on page 4-232) 133K26363
3. 1GB SO-DIMM (Extension System Memory) (REP 12.19 Memory
(Optional) on page 4-234)
237E25731
4. HDD Bracket
5. ESS Fan Bracket
6. I/P PWB Fan (REP 12.20 Image Processor PWB Fan on page 4-235) 127E86110
7. USB Panel
8. USB Host Panel
9. EPSV Panel
10. Serial Debug Panel
11. -----
12. PCI Screw
13. ESS Interface Plate Assembly
14. Plate
15. -----
16. -----
17. -----
18. -----
19. -----
20. HDD Productivity Service Kit (REP 12.21 Hard Disk Drive (Optional)
on page 4-236)
604K78960
