Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-39
Power Signal Lines
Signal Line Name Description
Relay On The On/ Off Control signal of the Interlock Relay in the LVPS
W-Box IL The Open Detection signal of the Waste Cartridge Set Switch
Toner IL The Open Detection signal of the Toner Cover Interlock Switch
Front IL The Open Detection signal of the Front Cover Interlock Switch
LVPS Type The Identification signal of the 100V/ 200 V LVPS system
Fan On The On/ Off Control signal of the LVPS Fan (MCU PWB > LVPS PWB)
Fan Low The rotation speed Switching signal of the LVPS Fan (MCU PWB > LVPS
PWB)
Fan Alarm The Alarm signal from the LVPS Fan (LVPS PWB > MCU PWB)
Power On The On/ Off Control signal of the voltage output (+3.3VDC, +5VDC,
+24VDC) from the LVPS
On The On/ Off Control signal of the LVPS Fan
Alarm The Alarm signal from the LVPS Fan

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
