Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-40
Overcurrent Protection
The various output from the LVPS each comes with an overcurrent protection. The status for each
output when a sort circuit has occurred between it and the Ground is shown in the following table.
Note: X: Output is stopped, -: Output is normal or stopped
Note: For the 3.3 Main, its output will return to normal after the short circuit is fixed. For the 5V
Standby, 24V, and 24V Interlock, the outputs can be restored by turning the power Off and
waiting for the specified time before turning it On again.
Overvoltage Protection
The various output from the LVPS each comes with an overvoltage protection. The status for the
various output during an overvoltage is shown in the following table.
Note: X: Output is stopped, -: Output is normal or stopped
Note: The outputs can be restored by turning the power Off and waiting for the specified time
before turning it On again.
Shorted
Output
Output Status Conditions
3.3V
Main
5V
Standby
5V Main 24V
24V
Interlock
3.3V Main X
--- -
4A or lower (Fuse)
5V StandbyXXXX X8 to 12A
5V Main X
--- -
4A or lower (Fuse)
24V
---
XX
-
24V Interlock
----
X 17 to 21A
Shorted
Output
Output Status Conditions
3.3V
Main
5V
Standby
5V Main 24V
24V
Interlock
3.3V MainXXXX X4.5V or lower
5V StandbyXXXX X8V or lower
5V Main XXXX X8V or lower
24V
---
X X 32V or lower
24V Interlock
---
X X 32V or lower

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
