Xerox Phaser 7100

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-22
950 880 Fuser Unit (100,000
pages)
PV A4 LEF imp simple
accumulation*1
950 884 Conducting
Time
Counts up in 1 minute
increments when the IOT Status
is ‘Standby’ or ‘Print’
950 888 IBT Unit (Transfer Belt)
(200,000 pages)
PV A4 LEF imp simple
accumulation*1
950 892 Rotation Time Calculated from the Drum Cycle
Frequency
* 1 Details on A4 LEF imp simple accumulation
Taking “L” as the paper length that is notified from the Controller to the MCU PWB.
a. L ≤ 216 mm (8.5 inch)*1 +1 (A4 LEF and Letter LEF or smaller)
b. L ≤ 216 mm (8.5 inch)*2 +2 (A3, and Legal or smaller)
c. L ≤ 216 mm (8.5 inch)*3 +3
d. L ≤ 216 mm (8.5 inch)*4 +4
e. L ≤ 216 mm (8.5 inch)*5 +5 (900 mm Long Paper)
f. 216 mm (8.5 inch)*5 < L +6 (1200 mm Long Paper)
DC135 HFSI Counter (Continued)
Chain Link Component Item Specifications
