Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-21
HFSI Counter Chain-Link Number List
DC135 HFSI Counter
Chain Link Component Item Specifications
950 800 Developer Housing
Assemblies (C/ M/ Y/ K)
(300,000 pages)
Yellow PV A4 LEF imp simple
accumulation*1
950 804 Magenta
950 808 Cyan
950 812 Black
950 816 Yellow Rotation Time Calculated from the Drum Cycle
Frequency
(Not used for determining Life)
950 820 Magenta
950 824 Cyan
950 828 Black
950 832 Yellow Pixel Count Pixel count accumulation
(Not used for determining Life)
950 836 Magenta
950 840 Cyan
950 844 Black
950 848 Bypass Tray Roller
(100,000 pages)
PV A4 LEF imp simple
accumulation*1
950 852 Tray 1 Feed Roller
(100,000 pages)
PV A4 LEF imp simple
accumulation*1
950 856 Tray 2, 3, 4 Feed Roller
(100,000 pages)
Tray 2 PV A4 LEF imp simple
accumulation*1
950 860 Tray 3
950 864 Tray 4
950 872 Transfer Roller (2nd BTR)
(100,000 pages)
PV A4 LEF imp simple
accumulation*1
950 876 Life Extension Kit
(300,000 pages)
• Dispense Motor (All
Colors)
• Registration Roller
•Trickle Motor
A4 LEF imp simple
accumulation*1
Note: It is it is recommended to
replace the Dispense Motor,
Registration Roller, and Trickle
Motor, and reset the life counter
when use the engine past the
rated life.
