Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-67
045
045-310 Image Ready NG 2-243
045-311 Controller Comm Fail (IOT Detect) 2-243
060
060-310 Warm Up Fail 2-244
061
061-340 ROS LD Fail K 2-244
061-346 SOS INT-Q Fail 2-244
071
071-101 Tray 1 Miss Feed Jam 2-246
072
072-101 Tray 2 Miss Feed Jam 2-248
072-103 Path 2 Sensor On Jam 2-250
072-310 Tray 2 Motor Fail 2-252
072-311 Tray 2 Mode Fail 2-253
073
073-101 Tray 3 Miss Feed Jam 2-254
073-103 Path 3 Sensor On Jam 2-256
073-310 Tray 3 Motor Fail 2-258
073-311 Tray 3 Mode Fail 2-259
074
074-101 Tray 4 Miss Feed Jam 2-260
074-310 Tray 4 Motor Fail 2-262
074-311 Tray 4 Mode Fail 2-263
075
075-100 Bypass Tray Miss Feed Jam 2-264
077
077-101 Registration Sensor Off Jam (Too Long) 2-266
Error Message and Chain Link Code Display (Continued)
Chain Link Control Panel Message Go to Page
