Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-255
5. Check the Paper Jam Sensor operation (Tray 3).
Perform DC330 Component Control on
page 2-26 [071-126] to check the operation of
the Paper Jam Sensor.
Is the Paper Jam Sensor operating normally?
Go to step 6. Go to Paper Jam
Sensor on page 2-443.
6. Check the Turn Roller Clutch operation (Tray 3).
Perform DC330 Component Control on
page 2-26 [071-030] to check the operation of
the Turn Roller Clutch.
Is the Turn Roller Clutch operating properly?
Go to step 7. Go to Turn Rolle r
Clutch (Tray 2/ 3/ 4) on
page 2-425.
7. Check the Feed Roller Clutch operation (Tray 3).
Perform DC330 Component Control on
page 2-26 [071-027] to check the operation of
the Feed Roller Clutch.
Is the Feed Roller Clutch operating properly?
Go to step 8. Go to Feed Roller
Clutch (Tray 2/ 3/ 4) on
page 2-428.
8. Check the Feeder Motor operation (Tray 3).
Perform DC330 Component Control on
page 2-26 [071-020] to check the operation of
the Feeder Motor.
Is the Feeder Motor operating normally?
Replace the MCU PWB
(REP 12.4 MCU PWB
on page 4-206).
Go to Option Feeder
Mode Error on
page 2-451.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
