Clearance and Mounting Surface Specifications
These specifications apply to any printer used as a table-top printer.
1. In order to function properly, the printer must be placed on a flat surface with the following
minimum clearances.
Standard Configuration
10 cm
3.9 in
10 cm
3.9 in
145.4 cm
57.2 in
76.2 cm
30.0 in
70 cm
27.6 in
13 cm
5.1 in
s7100-164
