Xerox Phaser 7100

Service Parts Disassembly
Xerox Internal Use Only Phaser 7100 Service Manual 4-17
Replacement Note: When installing the Waste Arm Support, make sure the Arm Support is seated
underneath the Waste Spring Hinge Cover (PL 1.1.37).
s7100-041
Waste Arm
Support
Waste Spring Hinge Cover
