Xerox Phaser 7100 Service Manual

Service Parts Disassembly
Xerox Internal Use Only Phaser 7100 Service Manual 4-127
Replacement Note: After installing the Right Latch Assembly, position the Link section of the Right
Latch Assembly as shown in Figure 2. If the Link section is not positioned correctly, it will not be
able to link with the IBT Unit which could damage the IBT Unit.
Figure 2
s7100-132
