Service Parts Disassembly
Xerox Internal Use Only Phaser 7100 Service Manual 4-181
IBT Unit Placement
Option 1
Place the removed IBT Unit on a flat surface that is free of any contamination, or dust, etc. with the
Waste Cartridge Assembly facing down.
Option 2
When there is a need to remove any parts that are installed on the IBT Unit, turn it over (from the
Option placement) and place it on a flat surface that is free of any contamination, or dust, etc. with the
Waste Cartridge Assembly facing up.
