Xerox Phaser 7100

Service Parts Disassembly
Phaser 7100 Service Manual Xerox Internal Use Only4-246
Replacement Note: Position the Left/ Right Rear Torsion Spring in between the 2 E-rings that are
attached to the Stopper Hinge Shaft.
s7100-399
Left Rear
Torsion Spring
