Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-30
Denotes a Photo Sensor.
Denotes an LED.
Denotes a Safety Interlock Switch.
Denotes an On-Off Switch (single-pole, single-throw switch).
Denotes an On-Off Switch (Temperature - normally close).
Denotes an NPN Photo-transistor.
Represents an interconnection between parts using wiring harness or wire.
Represents an interconnection which differs according to the specifications.
Symbol Description
Optic Sensor
LED
Safety Interlock Switch
On Off Switch
Temperature Switch
Interconnection
Interconnection, Differing

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
