Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-25
Analog Monitor Check List (Input)
Chain Link Component Description
010 200 Fuser Non-contact Sensor Voltage
Compensation
The compensation element voltage of the
Fuser Non-contact Sensor.
010 201 Fuser Non-contact Sensor Voltage The detection element voltage of the Fuser
Non-contact Sensor.
010 202 Fuser Non-contact Sensor Voltage
Difference
The difference between detection and
compensation voltage of the Fuser Non-
contact Sensor.
010 203 Fuser Soft Touch Sensor The sensor detection voltage at the Fuser
terminal contact.
046 200 Black 1st Transfer Voltage Monitor The voltage monitor value of the 1st BTR (K).
046 201 2nd BTR Current Monitor The voltage monitor value of the 2nd BTR.
092 200 Left CTD Sensor Voltage The density detection signal voltage value of
the Left CTD Sensor.
092 201 Right CTD Sensor Voltage The density detection signal voltage value of
the Right CTD Sensor.
061 200 ROS Temperature Sensor The detected temperature at the Thermo
Sensor that is part of the CTD Sensor
Assembly.
091 201 Environment Sensor Humidity The detected humidity at the Humidity
Sensor.
091 202 Environment Sensor Temperature The detected temperature at the Humidity
Sensor.
