Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-29
071 106 Paper Size Sensor 0 Detects the High/ Low states of Switch 0 of
the Paper Size Switch (PL 2.1.6) (Tray 1)
071 107 Paper Size Sensor 1 Detects the High/ Low states of Switch 1 of
the Paper Size Switch (PL 2.1.6) (Tray 1)
071 108 Paper Size Sensor 2 Detects the High/ Low states of Switch 2 of
the Paper Size Switch (PL 2.1.6) (Tray 1)
071 109 Paper Size Sensor 3 Detects the High/ Low states of Switch 3 of
the Paper Size Switch (PL 2.1.6) (Tray 1)
071 110 Option Feeder 1 Paper Size Sensor 0 Detects the High/ Low states of Switch 0 of
the Paper Size Switch (PL 15.1.5) (Tray 2)
071 111 Option Feeder 1 Paper Size Sensor 1 Detects the High/ Low states of Switch 1 of
the Paper Size Switch (PL 15.1.5) (Tray 2)
071 112 Option Feeder 1 Paper Size Sensor 2 Detects the High/ Low states of Switch 2 of
the Paper Size Switch (PL 15.1.5) (Tray 2)
071 113 Option Feeder 1 Paper Size Sensor 3 Detects the High/ Low states of Switch 3 of
the Paper Size Switch (PL 15.1.5) (Tray 2)
071 114 Option Feeder 2 Paper Size Sensor 0 Detects the High/ Low states of Switch 0 of
the Paper Size Switch (PL 15.1.5) (Tray 3)
071 115 Option Feeder 2 Paper Size Sensor 1 Detects the High/ Low states of Switch 1 of
the Paper Size Switch (PL 15.1.5) (Tray 3)
071 116 Option Feeder 2 Paper Size Sensor 2 Detects the High/ Low states of Switch 2 of
the Paper Size Switch (PL 15.1.5) (Tray 3)
071 117 Option Feeder 2 Paper Size Sensor 3 Detects the High/ Low states of Switch 3 of
the Paper Size Switch (PL 15.1.5) (Tray 3)
071 118 Option Feeder 3 Paper Size Sensor 0 Detects the High/ Low states of Switch 0 of
the Paper Size Switch (PL 15.1.5) (Tray 4)
071 119 Option Feeder 3 Paper Size Sensor 1 Detects the High/ Low states of Switch 1 of
the Paper Size Switch (PL 15.1.5) (Tray 4)
071 120 Option Feeder 3 Paper Size Sensor 2 Detects the High/ Low states of Switch 2 of
the Paper Size Switch (PL 15.1.5) (Tray 4)
071 121 Option Feeder 3 Paper Size Sensor 3 Detects the High/ Low states of Switch 3 of
the Paper Size Switch (PL 15.1.5) (Tray 4)
071 122 Option Feeder 1 No Paper Sensor Detects the High/ Low states of the No Paper
Sensor (PL 15.2.8) (Tray 2)
071 123 Option Feeder 2 No Paper Sensor Detects the High/ Low states of the No Paper
Sensor (PL 15.2.8) (Tray 3)
Input (Continued)
Chain Link Component Description

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
