Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-30
071 124 Option Feeder 3 No Paper Sensor Detects the High/ Low states of the No Paper
Sensor (PL 15.2.8) (Tray 4)
071 125 Option Feeder 1 Paper Jam Sensor Detects the High/ Low states of the Paper
Jam Sensor (PL 15.2.3) (Tray 2)
071 126 Option Feeder 2 Paper Jam Sensor Detects the High/ Low states of the Paper
Jam Sensor (PL 15.2.3) (Tray 3)
071 127 Option Feeder 3 Paper Jam Sensor Detects the High/ Low states of the Paper
Jam Sensor (PL 15.2.3) (Tray 4)
071 128 Duplex Unit Paper Jam Sensor Detects the High/ Low states of the Duplex
Jam Sensor (PL 14.3.17)
071 200 Yellow Magenta Cyan Drum Motor
Alarm
Detects the Alarm Signal of the Drum Motor
(PR Drive Assembly) (Y/ M/ C) (PL 11.1.2)
071 201 Black Drum Motor Alarm Detects the Alarm Signal of the Drum Motor
(PR Drive Assembly) (K) (PL 11.1.12)
071 202 Paper Handling Motor Alarm Detects the Alarm Signal of the Paper
Handling Motor (PL 11.1.19)
071 203 Option Feeder 1 Motor Alarm Detects the Alarm Signal of the Feeder Motor
(Option Drive Assembly) (Tray 2) (PL 15.2.28)
071 204 Option Feeder 2 Motor Alarm Detects the Alarm Signal of the Feeder Motor
(Option Drive Assembly) (Tray 3) (PL 15.2.28)
071 205 Option Feeder 3 Motor Alarm Detects the Alarm Signal of the Feeder Motor
(Option Drive Assembly) (Tray 4) (PL 15.2.28)
093 200 Yellow Developer Motor Alarm Detects the Alarm Signal of the Developer
Motor (Y) (PL 11.1.17)
093 201 Magenta Developer Motor Alarm Detects the Alarm Signal of the Developer
Motor (M) (PL 11.1.17)
093 202 Cyan Developer Motor Alarm Detects the Alarm Signal of the Developer
Motor (C) (PL 11.1.17)
093 203 Black Developer Motor Alarm Detects the Alarm Signal of the Developer
Motor (K) (PL 11.1.17)
093 209 Waste Toner Cartridge Full Sensor Detects the High/ Low states of the Waste
Cartridge Full Sensor (PL 9.1.5)
094 200 Belt Retract Sensor Detects the High/ Low states of the Belt
Retract Sensor (CAM Assembly) (PL 9.1.8)
Input (Continued)
Chain Link Component Description

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
