Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-31
Component Check List (Output)
Output
Chain Link Component Description Limitations
010 001 Fuser Motor
(Normal)
Drives the Fuser Motor (Fuser
Drive Assembly) (PL 4.2.16)
(Normal Speed: Forward
Rotation)
010 002 Fuser Motor (1/2) Drives the Fuser Motor (Fuser
Drive Assembly) (PL 4.2.16)
(1/2 Speed: Forward
Rotation)
010 005 Fuser Relay Turns On the Fuser Relay
041 002 LVPS 24V Outputs +24VDC from the
LVPS PWB (PL 12.2.1)
042 002 Developer Fan Drives the Developer Fan (PL
12.2.16)
042 003 LVPS Fan (Normal) Drives the LVPS Fan (PL
12.2.22)
(Normal Speed)
042 004 LVPS Fan (1/2) Drives the LVPS Fan (PL
12.2.22)
(1/2 Speed)
042 005 HVPS2 Fan
(Normal)
Drives the HVPS2 Fan (PL
12.1.3)
(Normal Speed)
042 006 HVPS2 Fan (1/2) Drives the HVPS2 Fan (PL
12.1.3)
(1/2 Speed)
061 001 ROS Motor Drives the ROS Motor (ROS
Assembly) (PL 7.1.1)
071 001 (Y/ M/ C) Drum
Motor (Normal)
Drives the Drum Motor (Y/ M/
C) (Drive Assembly) (PL 11.1.2)
(Normal Speed: Forward
Rotation)
Remove the Imaging Unit (Y/ M/
C) or the IBT Unit. If the rotation
is performed without these
removed, it will damage the
Drum and the Belt.
Even with the IBT Unit removed,
rotating the Drum (Y/ M/ C) this
way for too long could cause the
blade to curl up.
071 002 (Y/ M/ C) Drum
Motor (1/2)
Drives the Drum Motor (Y/ M/
C) (Drive Assembly) (PL 11.1.2)
(1/2 Speed: Forward Rotation)
