Xerox Phaser 7100

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-32
071 005 Black Drum Motor
(Normal)
Drives the Drum Motor (K)
(PL 11.1.12)
(Normal Speed: Forward
Rotation)
Remove the Imaging Unit (Y/ M/
C) or the IBT Unit. If the rotation
is performed without these
removed, it will damage the
Drum and the Belt.
Even with the IBT Unit removed,
rotating this way for too long
could cause the blade to curl up.
Also, even with the Imaging Unit
(Y/ M/ C) removed, rotating this
way for too long could cause the
IBT blade to curl up.
071 006 Black Drum Motor
(1/2)
Drives the Drum Motor (K)
(PL 11.1.12)
(1/2 Speed: Forward Rotation)
071 007 Black Drum Motor
(Reverse Normal)
Drives the Drum Motor (K)
(PL 11.1.12)
(Normal Speed: Reverse
Rotation)
Remove the Imaging Unit (Y/ M/
C/ K) or the IBT Unit. If the
rotation is performed without
these removed, it will damage
the Drum and the Belt.
Even with the Imaging Unit (Y/
M/ C/ K) removed, rotating this
way could cause Toner
contamination (which will also
affect the 2nd BTR) from the IBT
Cleaner.
071 008 Black Drum Motor
(Reverse 1/2)
Drives the Drum Motor (K)
(PL 11.1.12)
(1/2 Speed: Reverse Rotation)
071 009 Paper Handling
Motor (Normal)
Drives the Paper Handling
Motor (PL 11.1.19)
(Normal Speed: Forward
Rotation)
071 010 Paper Handling
Motor (1/2)
Drives the Paper Handling
Motor (PL 11.1.19)
(1/2 Speed: Forward Rotation)
071 013 Registration Clutch Turns On the Registration
Clutch (PL 5.1.11)
071 014 Bypass Tray Feed
Solenoid
Turns On the Bypass Tray Feed
Solenoid (PL 4.3.10)
071 015 Feed Clutch Turns On the Feed Roller Clutch
(PL 2.2.8)
071 016 Turn Clutch Turns On the Turn Roller Clutch
(PL 5.1.9)
071 017 Duplex Unit Clutch Turns On the Duplex Clutch
(PL 14.2.20)
Output (Continued)
Chain Link Component Description Limitations
