Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-33
071 018 Option Feeder 1
Motor (Normal)
Drives the Feeder Motor
(PL 15.2.28) (Tray 2)
(Normal Speed)
071 019 Option Feeder 1
Motor (1/2)
Drives the Feeder Motor
(PL 15.2.28) (Tray 2)
(1/2 Speed)
071 020 Option Feeder 2
Motor (Normal)
Drives the Feeder Motor
(PL 15.2.28) (Tray 3)
(Normal Speed)
071 021 Option Feeder 2
Motor (1/2)
Drives the Feeder Motor
(PL 15.2.28) (Tray 3)
(1/2 Speed)
071 022 Option Feeder 3
Motor (Normal)
Drives the Feeder Motor
(PL 15.2.28) (Tray 4)
(Normal Speed)
071 023 Option Feeder 3
Motor (1/2)
Drives the Feeder Motor
(PL 15.2.28) (Tray 4)
(1/2 Speed)
071 024 Duplex Unit Motor
(Normal)
Drives the Duplex Motor
(PL 14.2.1)
(Normal Speed)
071 025 Duplex Unit Motor
(1/2)
Drives the Duplex Motor
(PL 14.2.1)
(1/2 Speed)
071 026 Option Feeder 1
Feed Clutch
Turns On the Feed Roller Clutch
(PL 15.2.13) (Tray 2)
071 027 Option Feeder 2
Feed Clutch
Turns On the Feed Roller Clutch
(PL 15.2.13) (Tray 3)
071 028 Option Feeder 3
Feed Clutch
Turns On the Feed Roller Clutch
(PL 15.2.13) (Tray 4)
071 029 Option Feeder 1
Turn Cl utch
Turns On the Turn Rol ler Clutch
(PL 15.2.25) (Tray 2)
071 030 Option Feeder 2
Turn Cl utch
Turns On the Turn Rol ler Clutch
(PL 15.2.25) (Tray 3)
071 031 Option Feeder 3
Turn Cl utch
Turns On the Turn Rol ler Clutch
(PL 15.2.25) (Tray 4)
Output (Continued)
Chain Link Component Description Limitations

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
