Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-35
091 008 Yellow Developer
Motor (1/2)
Drives the Developer Motor (Y)
(PL 11.1.17)
(1/2 Speed)
Before turning this On, rotate the
Imaging Unit (071-002) first.
Attempting to rotate the
Developer Motor without
rotating the Imaging Unit first
could cause damage to the Drum
and risk internal printer
contamination due to toner.
091 009 Magenta
Developer Motor
(Normal)
Drives the Developer Motor
(M) (PL 11.1.17)
(Normal Speed)
Before turning this On, rotate the
Imaging Unit (071-001) first.
Attempting to rotate the
Developer Motor without
rotating the Imaging Unit first
could cause damage to the Drum
and risk internal printer
contamination due to toner.
091 010 Magenta
Developer Motor
(1/2)
Drives the Developer Motor
(M) (PL 11.1.17)
(1/2 Speed)
Before turning this On, rotate the
Imaging Unit (071-002) first.
Attempting to rotate the
Developer Motor without
rotating the Imaging Unit first
could cause damage to the Drum
and risk internal printer
contamination due to toner.
091 011 Cyan Developer
Motor (Normal)
Drives the Developer Motor (C)
(PL 11.1.17)
(Normal Speed)
Before turning this On, rotate the
Imaging Unit (071-001) first.
Attempting to rotate the
Developer Motor without
rotating the Imaging Unit first
could cause damage to the Drum
and risk internal printer
contamination due to toner.
091 012 Cyan Developer
Motor (1/2)
Drives the Developer Motor (C)
(PL 11.1.17)
(1/2 Speed)
Before turning this On, rotate the
Imaging Unit (071-002) first.
Attempting to rotate the
Developer Motor without
rotating the Imaging Unit first
could cause damage to the Drum
and risk internal printer
contamination due to toner.
Output (Continued)
Chain Link Component Description Limitations
