Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-36
093 003 Yellow Toner
Dispense Motor
Drives the Toner Dispense
Motor (Y) (Dispense Motor)
(PL 8.1.15)
Before turning this On, rotate the
Developer (091-007) first, and
also rotate the Developer for a
while (approx. 30 s) after turning
it Off.
As rotating this way for too long
will cause contamination in the
printer and background
appearing on the paper due to
toner cloud; perform the check
only in short time periods.
093 004 Magenta Toner
Dispense Motor
Drives the Toner Dispense
Motor (M) (Dispense Motor)
(PL 8.1.15)
Before turning this On, rotate the
Developer (091-009) first, and
also rotate the Developer for a
while (approx. 30 s) after turning
it Off.
As rotating this way for too long
will cause contamination in the
printer and background
appearing on the paper due to
toner cloud; perform the check
only in short time periods.
093 005 Cyan Toner
Dispense Motor
Drives the Toner Dispense
Motor (C) (Dispense Motor)
(PL 8.1.15)
Before turning this On, rotate the
Developer (091-011) first, and
also rotate the Developer for a
while (approx. 30 s) after turning
it Off.
As rotating this way for too long
will cause contamination in the
printer and background
appearing on the paper due to
toner cloud; perform the check
only in short time periods.
093 006 Black Toner
Dispense Motor
Drives the Toner Dispense
Motor (K) (Dispense Motor)
(PL 8.1.15)
Before turning this On, rotate the
Developer (091-003 to ‘01’) first,
and also rotate the Developer for
a while (approx. 30 s) after
turning it Off.
As rotating this way for too long
will cause contamination in the
printer and background
appearing on the paper due to
toner cloud; perform the check
only in short time periods.
Output (Continued)
Chain Link Component Description Limitations

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
