Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-64
024-933 Operation Y Imaging Unit End of Life 2-196
024-934 Paper Type Mismatch 2-197
024-940 Operation M Imaging Unit End of Life 2-196
024-941 Operation C Imaging Unit End of Life 2-196
024-946 Tray 1 Out Of Place 2-198
024-947 Tray 2 Out Of Place 2-198
024-948 Tray 3 Out Of Place 2-198
024-949 Tray 4 Out Of Place 2-198
024-950 Tray 1 Empty 2-199
024-951 Tray 2 Empty 2-201
024-952 Tray 3 Empty 2-201
024-953 Tray 4 Empty 2-201
024-954 Bypass Tray Empty 2-203
024-958 Bypass Tray Size Mismatch 2-205
024-959 Tray 1 Size Mismatch 2-193
024-960 Tray 2 Size Mismatch 2-193
024-961 Tray 3 Size Mismatch 2-193
024-962 Tray 4 Size Mismatch 2-193
024-965 ATS/APS No Paper APS/ ATS NG (No Paper) 2-205
024-966 ATS/APS No Destination Error APS/ ATS NG 2-206
024-985 Bypass Tray Pause Check 2-206
025
025-596 An NG occurred when HDD Fail Forecast of Diagnostics was executed 2-207
025-597 An error occurred when HDD initialization of Diagnostics was executed 2-207
026
026-704 XDW Error 2-208
026-705 XDW Short of Memory 2-208
026-706 XDW Print Prohibited 2-209
026-707 XDW Unlock Failed 2-209
Error Message and Chain Link Code Display (Continued)
Chain Link Control Panel Message Go to Page

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
