2 Parameters
2.1 Overview of parameters
SINAMICS DCM
14 List Manual (LH8), 02/2015, 6RX1800-0ED76
2.1 Overview of parameters
2.1.1 Explanation of the list of parameters
Basic structure of the parameter descriptions
The data in the following example have been chosen at random. The description of a
parameter includes as a maximum, the information listed below. Some of the information is
optional.
The "List of parameters" (Page 28) has the following structure:
- - - - - - - - - - - - Start of example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Description: Text
Value: 0: Name and meaning of value 0
1: Name and meaning of value 1
2: Name and meaning of value 2
etc.
Recommendation: Text
Index: [0] = Name and meaning of index 0
[1] = Name and meaning of index 1
[2] = Name and meaning of index 2
etc.
Dependency: Text
Refer to: pxxxx, rxxxx
Refer to: Fxxxxx, Axxxxx
Note: Information that might be useful.
- - - - - - - - - - - - End of example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
The individual pieces of information are described in detail below.
pxxxx[0...n] BICO: Full parameter name / abbreviated name
Drive object
(function module)
Can be changed: C1(x), C2(x), U, T Calculated: CALC_MOD_REG Access level: 2
Data type: Unsigned32 / Integer16 Dyn. index: CDS, p0170 Func. diagram: 8070
P-Group: Closed-loop control Unit group: 7_1 Unit selection: p0505
Not for motor type: ASM Scaling: p2000 Expert list: 1
Min Max Factory setting
0.00 [Nm] 10.00 [Nm] 0.00 [Nm]
Bit field: Bit Signal name 1 signal 0 signal FP
00 Name and meaning of bit 0 Yes no 8060
01 Name and meaning of bit 1 Yes no
02 Name and meaning of bit 2 Yes no 8065
etc.
Danger: Warning: Caution: Safety notices with a warning triangle
Notice: Safety notice without a warning triangle
