SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
25
2 Parameters
2.1 Overview of parameters
2.1.2 Number ranges of parameters
Number ranges for SINAMICS in general
Parameters are grouped into the following number ranges:
Note:
The following number ranges represent an overview of all parameters available for the
SINAMICS drive family.
The parameters for the product described in this List Manual are described in detail in "List of
parameters" (Page 28).
Table 2-3 Number ranges for SINAMICS
Range Description
From To
0000 0099 Display and operation
0100 0199 Commissioning
0200 0299 Power section
0300 0399 Motor
0400 0499 Encoder
0500 0599 Technology and units, motor-specific data, probes
0600 0699 Thermal monitoring, maximum current, operating hours, motor data,
central probe
0700 0799 Control Unit terminals, measuring sockets
0800 0839 CDS, DDS data sets, motor changeover
0840 0879 Sequence control (e.g. signal source for ON/OFF1)
0880 0899 ESR, parking, control and status words
0900 0999 PROFIBUS/PROFIdrive
1000 1199 Setpoint channel (e.g. ramp-function generator)
1200 1299 Functions (e.g. motor holding brake)
1300 1399 U/f control
1400 1799 Closed-loop control
1800 1899 Gating unit
1900 1999 Power unit and motor identification
2000 2009 Reference values
2010 2099 Communication (fieldbus)
2100 2139 Faults and alarms
2140 2199 Signals and monitoring
2200 2359 Technology controller
2360 2399 Staging, hibernation
