Siemens SINAMICS DCM List Manual

SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
467
2 Parameters
2.2 List of parameters
6: PT100
7: NTC thermistor K227
8: PT1000
Dependency: Refer to: r50012, r52051
Refer to: F60029, A60032
Note: Comments regarding PTC thermistors:
- PTC thermistors according to DIN 44081 / 44082 with the specified R for the rated response temperature.
- For Siemens motors, PTC thermistors with 1330 Ohm are used.
- Parameters p50491 and p50492 (alarm and switch-off temperature) are ineffective. The alarm and switch-off
temperatures are defined by the PTC thermistor type being used.
Comments on NTC thermistor K227:
The evaluation electronics on the CUD only allow resistance values of less than approx. 2 kOhm to be measured. As
a consequence, only temperatures greater than approx. 90 °C can be measured when using these temperature
sensors. For lower temperatures, the lowest possible value (approx. 90 °C) is displayed.
Description: Sets the alarm threshold for monitoring the motor temperature.
Dependency: The parameter is only valid for the following temperature sensors with a continuous characteristic:
- KTY84 (p50490 = 1)
- PT100 (p50490 = 6)
- NTC thermistor K227 (p50490 = 7)
- PT1000 (p50490 = 8)
Refer to: p50490, p50492, r52051
Refer to: A60032
Description: Sets the fault threshold for monitoring the motor temperature.
Dependency: The parameter is only valid for the following temperature sensors with a continuous characteristic:
- KTY84 (p50490 = 1)
- PT100 (p50490 = 6)
- NTC thermistor K227 (p50490 = 7)
- PT1000 (p50490 = 8)
Refer to: p50490, p50491, r52051
Refer to: F60029
p50491[0...n] Motor interface alarm threshold for temperature monitoring / Mot_temp al thr
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 8030
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0 [°C] 200 [°C] 0 [°C]
p50492[0...n] Motor interface fault threshold for temperature monitoring / Mot_temp flt thr
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 8030
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0 [°C] 200 [°C] 0 [°C]
