Siemens SINAMICS DCM List Manual

SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
257
2 Parameters
2.2 List of parameters
Value: 0: Trace inactive
1: Trace is recording presamples
2: Trace is waiting for trigger event
3: Trace is recording
4: Recording (trace) ended
Index: [0] = Trace 0
[1] = Trace 1
Description: Displays the actual status of the measuring function.
Value: 0: Measurement function inactive
1: Measuring function parameterization checked
2: Measuring function waits for stabilizing time
3: Measuring function recording (tracing)
4: Measuring function trace ended with error
5: Measuring function trace successfully completed
Description: Setting to configure the measurement function.
Value: 0: Standard
1: Free meas fct
Dependency: The parameter cannot be changed when the measurement function has been started (r4706 = 2, 3).
Note: This parameter involves the free measuring functions and is only active for p4810=6.
For value = 0:
The free measuring function is parameterized with master control.
For value = 1:
The free measuring function is parameterized without master control.
Description: Displays the required memory in bytes for the actual parameterization.
Index: [0] = Trace 0
[1] = Trace 1
Dependency: Refer to: r4799
r4706 Measuring function status / Meas fct status
CU_DC, CU_DC_R,
CU_DC_R_S,
CU_DC_S
Can be changed: - Calculated: - Access level: 3
Data type: Integer16 Dyn. index: - Func. diagram: -
P-Group: Trace and function generator Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 0
Min Max Factory setting
0 5 -
p4707 Measurement function configuration / Meas fct config
CU_DC, CU_DC_R,
CU_DC_R_S,
CU_DC_S
Can be changed: U, T Calculated: - Access level: 3
Data type: Integer16 Dyn. index: - Func. diagram: -
P-Group: Trace and function generator Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 0
Min Max Factory setting
0 1 0
r4708[0...1] Trace memory space required / Trace mem required
CU_DC, CU_DC_R,
CU_DC_R_S,
CU_DC_S
Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dyn. index: - Func. diagram: -
P-Group: Trace and function generator Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 0
Min Max Factory setting
- - -
