SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
497
2 Parameters
2.2 List of parameters
Description: Sets the signal source for the selection of connector 0 (p50431[0]).
Dependency: Refer to: p50430, p50431
Description: Sets the signal source for the selection of connector 1 (p50431[1]).
Dependency: Refer to: p50430, p50431
Description: Sets the signal source to enable droop on the speed controller.
Note: The following values are multiplied by the droop output dependent upon the signal state:
1 signal: Enable (r50630)
0 signal: No enable (0%)
Description: Sets the signal source for the master or slave drive on the speed controller.
Note: 1 signal:
Torque control is active on the slave drive.
0 signal:
Speed control is active on the master drive.
p50680[0...n] BI: Fixed setpoint signal source for connector selection 0 / Fix set con0 sig s
DC_CTRL Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dyn. index: CDS, p0170 Func. diagram: 3115
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 0
p50681[0...n] BI: Fixed setpoint signal source for connector selection 1 / Fix set con1 sig s
DC_CTRL Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dyn. index: CDS, p0170 Func. diagram: 3115
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 0
p50684[0...n] BI: Speed controller droop enable / Droop enable
DC_CTRL Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dyn. index: CDS, p0170 Func. diagram: 6805
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 1
p50687[0...n] BI: Speed controller signal source for master/slave drive / Mast/sl sig s
DC_CTRL Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dyn. index: CDS, p0170 Func. diagram: 6810, 6830
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 0
