2 Parameters
2.2 List of parameters
SINAMICS DCM
528 List Manual (LH8), 02/2015, 6RX1800-0ED76
Index 0 (FP3130):
The switch-on command and the intervention of r0807.0 and r53010.2 are always active.
Index 2 (FP6810):
The "speed actual value selection" is always active.
Value: 0: Control block de-activated
1: Control block activated
Index: [0] = Speed setpoint processing (FP3105 to FP3135)
[1] = RFG (FP3150 to FP3155)
[2] = Closed-loop speed control (FP6800 to FP6820)
[3] = Torque limiting/Current limitation (FP6825 to FP6845, FP8040)
[4] = Closed-loop armature current control (FP6852 to FP6855)
[5] = EMF setpoint processing and control (FP6900)
[6] = Closed-loop field current control (FP6905 to FP6910)
Note: This parameter is only evaluated once while powering up, i.e. a change only becomes effective after a new start or
after powering up with saved parameters (p0976 = 11).
The ability to de-activate control function blocks has been designed for users who set up their own control
configurations using Drive Control Chart (DCC) (e.g. synchronous generator field winding instead of running a
motor). De-activating control function blocks which are not needed frees up CPU time for the DCC blocks.
Description: Displays the operating hours for the device fan.
Index: [0] = Fan terminal XV1
[1] = Fan terminal XV2
[2] = Fan terminal XV3
[3] = Fan terminal XV4
[4] = Fan ON
Dependency: Refer to: p50961, p50962
Refer to: A60165
Note: The operating hours from "fan on" are only increased for the Control Module.
Description: Sets the service life for the device fan.
Index: [0] = Fan terminal XV1
[1] = Fan terminal XV2
[2] = Fan terminal XV3
[3] = Fan terminal XV4
[4] = Fan ON
Dependency: Refer to: r50960, p50962
Refer to: A60165
Note: An appropriate alarm is issued 500 hours before the set service life expires.
r50960[0...4] Device fan operating hours display / Dev_fan h disp
DC_CTRL Can be changed: - Calculated: - Access level: 1
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 8045
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- [h] - [h] - [h]
p50961[0...4] Device fan service life / Dev_fan serv life
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 8045
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0 [h] 1000000 [h] [0...3] 30000 [h]
[4] 0 [h]
