SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
493
2 Parameters
2.2 List of parameters
Dependency: The setting value for the ramp-function generator output is selected via binector input p50640.
p50640 = 0 signal:
If the machine is not running, the value supplied via connector input p50639[1] is accepted.
p50640 = 1 signal:
The value supplied via connector input p50639[0] is accepted as the setting value.
Refer to: p50640
Description: Sets the signal source for accepting the setting value of the ramp-function generator.
Dependency: Refer to: p50639
Description: Sets the signal source for "Bypass ramp-function generator".
Note: The "Bypass ramp-function generator" signal can also be set via binector input p50649[0 to 2].
Description: Sets the signal source for variable positive limiting of the main setpoint.
Notice: Negative values at the selected parameters generate a negative maximum value at the limiting output.
Note: The minimum of the values set via index 0 to 3 is applied as the limit.
Description: Sets the signal source for variable positive limiting of the main setpoint.
Notice: Positive values at the selected parameters generate a positive minimum value at the limiting output.
Note: The maximum of the values set via index 0 to 3 is applied as the limit.
p50640[0...n] BI: RFG signal source for accepting setting value / RFG accept set v
DC_CTRL Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dyn. index: CDS, p0170 Func. diagram: 3152
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 0
p50641[0...n] BI: Bypass ramp-function generator signal source / Bypass RFG sig s
DC_CTRL Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dyn. index: CDS, p0170 Func. diagram: 3152
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - 0
p50642[0...3] CI: Setpoint processing sig source for pos limiting of main setpoint / M set lim p sig s
DC_CTRL Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dyn. index: - Func. diagram: 3135
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
- - 52002[0]
p50643[0...3] CI: Setpoint processing sig source for neg limiting of main setpoint / M set lim n sig s
DC_CTRL Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dyn. index: - Func. diagram: 3135
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
- - [0] 52184[0]
[1] 52185[0]
[2] 52186[0]
[3] 52187[0]
