SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
531
2 Parameters
2.2 List of parameters
Description: Displays the order number (MLFB) of the connected Converter Commutation Protector (CCP).
Value: 0: No CCP connected
250: 6RA7085-6FC00-0
251: 6RA7091-6FC00-0
252: 6RA7095-6FC00-0
253: 6RA7090-6KC00-0
254: 6RA7095-6KC00-0
Description: Displays the rated supply voltage according to the rating plate of the Converter Commutation Protector (CCP).
Description: Displays the rated current according to the rating plate of the Converter Commutation Protector (CCP).
Description: Display and connector output for the state of the Converter Commutation Protector (CCP).
r51570 CCP order number / CCP Order No.
DC_CTRL Can be changed: - Calculated: - Access level: 3
Data type: Integer16 Dyn. index: - Func. diagram: 6970
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0 254 -
r51571 CCP rated supply voltage / CCP V_rated
DC_CTRL Can be changed: - Calculated: - Access level: 3
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 6970
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- [V] - [V] - [V]
r51572 CCP rated current / CCP I_rated
DC_CTRL Can be changed: - Calculated: - Access level: 3
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 6970
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
r51574.0...12 CO/BO: CCP state / CCP state
DC_CTRL Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dyn. index: - Func. diagram: 6970
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Voltage at U, V, W ok Yes No 6970
01 Voltage at C - D greater than +100 V Yes No 6970
02 Voltage at C - D less than -100 V Yes No 6970
03 Turn-off capacitors have reached the
setpoint voltage
Yes No 6970
04 Turn-off in progress Yes No 6970
05 Connection between parallel CCPs OK Yes No 6970
08 Connector X165_2 (at DCM) is connected
with X165 (at CCP)
Yes No 6970
09 I2t value voltage limiting chopper 1 too high Yes No 6970
10 I2t value voltage limiting chopper 2 too high Yes No 6970
11 Memory for technical data for CCP OK Yes No 6970
12 Chopper capacitors pre-charging completed Yes No 6970
