SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
541
2 Parameters
2.2 List of parameters
Description: Sets the save interval,
during which the signals recorded internally are saved to the following recording file:
\USER\SINAMICS\DATA\LOG\Track.csv
Dependency: Refer to: p51700, p51701, p51702, p51703, p51705, p51706
Notice: The value is set in minutes.
Description: Setting to start and stop the recorder function.
Value = 1:
Recording is started and stopped after reaching of the number of entries set in p51706. p51705 is set to 0.
Value = 2:
Recording is started: After reaching of the number of entries set in p51706, the file is overwritten from the beginning.
Recording runs until it is stopped by setting of p51705 = 0.
Value: 0: Stop
1: Start
2: Start with overwrite
Dependency: Refer to: p51700, p51701, p51702, p51703, p51704, p51706
Notice: Starting the recorder function overwrites any existing recording file.
Description: Sets the number of entries in the recorder function's recording file.
Dependent upon the start command (p51705 = 1 or 2), recording is stopped after this number of entries has been
reached or the recording file is overwritten from the beginning.
Dependency: Refer to: p51700, p51701, p51702, p51703, p51704, p51705
Description: All fault message responses are not immediately initiated, but only after a parameterizable delay time.
p51704 Recorder function save interval / Rec fct t_save
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: Unsigned32 Dyn. index: - Func. diagram: 8050
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
1 60 1
p51705 Start/stop recorder function / Rec fct StartStop
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: Integer16 Dyn. index: - Func. diagram: 8050
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0 2 0
p51706 Recorder function number of entries / Rec fct num ent
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: Unsigned32 Dyn. index: - Func. diagram: 8050
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
10 100000 3600
p51780 Fault message response delay time / F delay_time
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 2651
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.000 [s] 60.000 [s] 0.000 [s]
