Siemens SINAMICS DCM List Manual

2 Parameters
2.2 List of parameters
SINAMICS DCM
522 List Manual (LH8), 02/2015, 6RX1800-0ED76
Description: Displays the voltages for the electronic power supply.
Index: [0] = P10 (+10 V)
[1] = N10 (-10 V)
Dependency: Refer to: r50824
Refer to: F60091, F60092
Note: For r50823[0]:
A voltage value outside the permissible limits will trigger fault F60091.
For r50823[1]:
A voltage value outside the permissible limits will trigger fault F60092.
Description: Displays the failure duration for the electronic power supply.
Dependency: Refer to: r50823
Description: Displays the compensation values for the armature power unit.
Description: Displays the compensation values for the field power unit.
r50823[0...1] Electronic power supply voltage display / Electr supp V disp
DC_CTRL Can be changed: - Calculated: - Access level: 1
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 8048
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: p2001 Expert list: 1
Min Max Factory setting
- [V] - [V] - [V]
r50824 Electronic power supply failure duration / Electr supp t_fail
DC_CTRL Can be changed: - Calculated: - Access level: 1
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 8048
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- [ms] - [ms] - [ms]
r50825[0...29] Armature power unit compensation values / PU arm comp val
DC_CTRL Can be changed: - Calculated: - Access level: 4
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 8054
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
r50826[0...15] Field power unit compensation values / PU field comp val
DC_CTRL Can be changed: - Calculated: - Access level: 4
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 8054
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
