2 Parameters
2.1 Overview of parameters
SINAMICS DCM
16 List Manual (LH8), 02/2015, 6RX1800-0ED76
BICO: Full parameter name / abbreviated parameter name
The following abbreviations can appear in front of the parameter name:
Drive object (function module)
A drive object (DO) is an independent, "self-contained" functional unit that has its own
parameters and, in some cases, faults and alarms.
When carrying out commissioning using the commissioning software, you can select/deselect
additional functions and their parameters by activating/deactivating function modules
accordingly.
The parameter list specifies the associated drive object and function module for each individual
parameter.
Example:
• r61000: PROFINET Name of Station
CU_DC (PROFINET)
The parameter is only available in the case of the CU_DC drive object with the “PROFINET”
function module.
A parameter can belong to one, several, or all drive objects.
The following information relating to "Drive object" and "Function module" can be displayed
under the parameter number:
Note:
The parameter list can contain parameters that are not visible in the expert lists of the particular
commissioning software (e.g. parameters for trace functions).
• BI: Binector Input
This parameter is used for selecting the source of a digital signal.
• BO: Binector Output
This parameter is available as a digital signal for interconnection with other
parameters.
• CI: Connector Input
This parameter is used for selecting the source of an "analog" signal.
• CO: Connector Output
This parameter is available as an “analog” signal for interconnection with other
parameters.
• CO/BO: Connector/Binector Output
This parameter is available as an “analog” and digital signal for interconnection
with other parameters.
Note:
A connector input (CI) cannot be just interconnected with any connector output (CO, signal
source).
When interconnecting a connector input using the commissioning software, only the
corresponding possible signal sources are listed.
