Siemens SINAMICS DCM List Manual

SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
461
2 Parameters
2.2 List of parameters
Value: 0: 1 level
1: 0/1 edge
Description: Setting to activate/de-activate the ramp-function generator on the motorized potentiometer.
Value: 0: RFG de-activated in automatic mode
1: RFG activated in automatic and manual modes
Description: Sets the signal source for the ramp-function generator's setpoint in automatic mode on the motorized potentiometer.
Description: Sets the ramp-up time on the motorized potentiometer.
Description: Sets the ramp-down time on the motorized potentiometer.
Description: Sets the time difference for the ramp-function generator dy/dt on the motorized potentiometer.
p50460[0...n] Motorized potentiometer activate ramp-function generator / Mot pot act RFG
DC_CTRL Can be changed: T Calculated: - Access level: 2
Data type: Integer16 Dyn. index: DDS, p0180 Func. diagram: 3110
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0 1 1
p50461[0...n] CI: Motorized potentiometer signal source for automatic setpoint / MotP aut s sig s
DC_CTRL Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / FloatingPoint32 Dyn. index: CDS, p0170 Func. diagram: 3110
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
- - 0
p50462[0...n] Motorized potentiometer ramp-up time / MotP t_r-up
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 3110
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.01 [s] 300.00 [s] 10.00 [s]
p50463[0...n] Motorized potentiometer ramp-down time / MotP t_r-dn
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 3110
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.01 [s] 300.00 [s] 10.00 [s]
p50464[0...n] Motorized potentiometer time difference for dy/dt / MotP t_dif dy/dt
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 3110
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.01 [s] 300.00 [s] 10.00 [s]
