Siemens SINAMICS DCM List Manual

2 Parameters
2.2 List of parameters
SINAMICS DCM
402 List Manual (LH8), 02/2015, 6RX1800-0ED76
Description: Sets the field circuit resistance.
Note: The parameter is set automatically during the optimization run for closed-loop field current control (p50051 = 24).
Description: Sets the permissible continuous armature current for motor I2t monitoring.
Note: At this permissible continuous current, fault F60037 is not output.
The current is calculated as follows: p50113 * p50100.
Description: Sets the thermal time constant of the motor.
Note: Value = 0:
The motor's I2t monitoring is de-activated.
Description: Setting of the percentage value in relation to p50078[0] for specifying the EMF at maximum speed.
The speed is adjusted using the EMF as the speed actual value.
Description: Sets the field circuit inductance.
Dependency: Refer to: p51597
p50112[0...n] Field circuit resistance / R_field circuit
DC_CTRL Can be changed: U, T Calculated: - Access level: 3
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 6910
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.000 [ohm] 4000.000 [ohm] 0.000 [ohm]
p50113[0...n] Motor I2t monitoring continuous current factor / Mot I2t I_cont
DC_CTRL Can be changed: U, T Calculated: - Access level: 2
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 8038
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.50 2.00 1.00
p50114[0...n] Motor thermal time constant / Mot T therm
DC_CTRL Can be changed: C2(1), U, T Calculated: - Access level: 1
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 8038
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0 [s] 10000 [s] 600 [s]
p50115[0...n] Speed controller EMF at maximum speed / EMF at n_max
DC_CTRL Can be changed: C2(1), U, T Calculated: - Access level: 1
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 6810
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
1.00 [%] 140.00 [%] 100.00 [%]
p50116[0...n] Field circuit inductance / L_field circuit
DC_CTRL Can be changed: U, T Calculated: - Access level: 3
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 6910
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
0.0 [mH] 1000000.0 [mH] 0.0 [mH]
