SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
21
2 Parameters
2.1 Overview of parameters
Dynamic index
For parameters with a dynamic index [0...n], the following information is specified here:
Data set (if available).
Parameter for the number of indices (n = number - 1).
This field can contain the following information:
“CDS, p0170” (Command Data Set, CDS count)
Example:
p1070[0] main setpoint [command data set 0]
p1070[1] main setpoint [command data set 1], etc.
“DDS, p0180” (Drive Data Set, DDS count)
“EDS, p0140” (Encoder Data Set, EDS count)
Function diagram
The parameter is included in this function diagram. The structure of the parameter function and
its relationship with other parameters is shown in the specified function diagram.
P-Group (refers only to access via BOP (Basic Operator Panel))
Specifies the functional group to which this parameter belongs. The required parameter group
can be set via p0004.
Unit, unit group and unit selection
The standard unit of a parameter is specified in square parentheses after the values for “Min”,
“Max”, and “Factory setting”.
Note:
Information on the data sets can be taken from the following references:
References: SINAMICS DC MASTER operating instructions
“Data sets” Chapter
Note:
Parameter p0004 is CU-specific (belongs to the Control Unit).
Note:
The units cannot be switched over for SINAMICS DCM.
The information under Unit Group and Unit Selection has no relevance.
