SINAMICS DCM
List Manual (LH8), 02/2015, 6RX1800-0ED76
483
2 Parameters
2.2 List of parameters
Dependency: Refer to: p50596, r53025
Description: Sets the signal source for the "Speed actual value polarity" message.
Dependency: Refer to: p50372, r53025
Description: Sets the signal source for the gating unit input on the armature circuit.
Description: Sets the signal source for the setpoint on the armature current controller.
Notice: Re index 5:
When entering a supplementary current setpoint via p50601[5] it is not permissible to use the current setpoint
integrator or the reduced gearbox load function. p50158 must be set = 0.000 s.
Possible effect if this is not observed:
Torque direction change will not be able to be completed. The drive remains in one torque direction.
Note: [0 to 1] = Speed limiting controller
Sets the signal sources for the setpoint on the speed limiting controller. The two values are added together.
[2 to 3] = Current limitation
Sets the signal sources for the setpoint on the current controller (before current limitation). The two values are added
together.
[4 to 5] = Closed-loop current control
Sets the signal sources for the setpoint on the current controller (before the current controller). The two values are
added together. The absolute value is generated from the value in index 5.
p50598[0...n] CI: Messages polarity speed actual value signal source / MsgPol n_act S_src
DC_CTRL Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / FloatingPoint32 Dyn. index: CDS, p0170 Func. diagram: 8025
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
- - 52179[0]
p50600[0...4] CI: Signal source for armature gating unit input / A g unit in sig s
DC_CTRL Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dyn. index: - Func. diagram: 6858, 6860
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
- - [0] 52102[0]
[1...4] 0
p50601[0...5] CI: Signal source for speed limiting controller setpoint / n_lim set sig s
DC_CTRL Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dyn. index: - Func. diagram: 6835, 6840,
6855
P-Group: - Unit group: - Unit selection: -
Not for motor type: - Scaling: PERCENT Expert list: 1
Min Max Factory setting
- - [0] 52141[0]
[1] 0
[2] 52134[0]
[3] 0
[4] 52125[0]
[5] 0
