Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-58
016-718 Insufficient PCL6 Decomposer Memory 2-127
016-719 Insufficient PCL Decomposer Memory 2-128
016-720 PCL Command Error Detected By PCL Decomposer 2-128
016-721 An unexpected error occurred at the PLW decomposer during printing. 2-129
016-726 Auto SW judgment has failed. 2-129
016-727 0-page Condition detected when storing print job in folder 2-130
016-728 Invalid TIFF File. The data contains a Tag that is not set in the Image File
Expansion Library.
2-130
016-729 Invalid TIFF File. The specified settings exceed the upper limit of the valid
number of colors and pixels.
2-131
016-730 ART Command Error. An unsupported command was detected at ART 2-131
016-731 Invalid TIFF File. The TIFF data is broken or cut off halfway. 2-132
016-732 <Form Overlay Error> Data itself is not printed when the form specified is
not registered in emulation.
2-132
016-734 Simple Destination Result Report Output Error 2-133
016-735 Updating Job Template. The system attempted to output the Job Template
List while the Job Template is being updated.
2-133
016-736 Repository Lock Error 2-134
016-737 Lock Directory Deletion Error 2-134
016-738 Invalid Paper Size for PS Booklet Print 2-135
016-739 PS Booklet Document/Output Paper Mismatch 2-135
016-740 Invalid Output Tray for PS Booklet Print 2-136
016-741 Unable to Transition to Download Mode 2-136
016-742 Product ID of Download Data was detected to be different. 2-137
016-743 Printer Model/ Panel Type Error Target model in the download data and the
printer model do not match.
2-137
016-744 Download Data Checksum Error 2-138
016-745 XPJL Fatal Error during Download 2-138
016-746 Sent PDF Contains Unsupported Function 2-139
016-747 Insufficient memory when drawing an annotation image 2-139
016-748 Full Status detected at folder access and job is canceled 2-140
016-749 PJL/ XPJL Detected an Unprintable Print Language 2-140
