Name Value Internal value Internal value,
type
Default
Process cycle
time
1 ms process
cycle time
1 BYTE 1 ms
2 ms process
cycle time
2
3 ms process
cycle time
3
4 ms process
cycle time
4
5 ms process
cycle time
5
6 ms process
cycle time
6
7 ms process
cycle time
7
8 ms process
cycle time
8
9 ms process
cycle time
9
10 ms process
cycle time
10
11 ms process
cycle time
11
12 ms process
cycle time
12
13 ms process
cycle time
13
14 ms process
cycle time
14
15 ms process
cycle time
15
16 ms process
cycle time
16
Check supply off
on
0
1
BYTE 1
Fast counter 0
:
10
2
)
0
:
10
BYTE 0
1
) With a faulty ID, the module reports a "parameter error" and does not perform cyclic process
data transmission.
2
) Counter operating modes Ä Chapter 1.5.1.2.10 “Fast Counter” on page 394
