ABB AC500 PLC - Technical Data of the Module

Parameter Value
Ethernet 100 base-TX, internal switch, 2x RJ45 socket
Expandability (S500 I/O Modules) Up to 10 S500 I/O Modules (Index C0 and
above), Not available(Index below C0)
Indicators 5 LEDs for state indication
Adjusting elements 2 rotary switches (used for future topology
extensions)
Quantity of input/output data CI512-ETHCAT: 10 bytes input and 14 bytes
output
CI511-ETHCAT: 18 bytes input and 18 bytes
output
Acyclic services SDO (1500 bytes max.)
Emergency ECAT_SLV_DIAG
Protective functions (according to COD-
ESYS)
Protected against:
● short circuit
● reverse supply
● overvoltage
● reverse polarity
Electrical isolation to network
Technical Data of the Module
Parameter Value
Process supply voltage UP/UP3
Rated value 24 VDC (for inputs and outputs)
Max. load for the terminals 10 A
Protection against reversed voltage Yes
Rated protection fuse on UP/UP3 10 A fast
Electrical isolation Ethernet interface against the rest of the
module
Inrush current from UP (at power up) On request
Current consumption via UP (normal
operation)
0.2 A
Current consumption via UP3 0.06 A + 0.5 A max. per output
Connections Terminals 1.8 and 2.8 for +24 V (UP)
Terminal 3.8 for +24 V (UP3)
Terminals 1.9, 2.9 and 3.9 for 0 V (ZP)
Max. power dissipation within the module 6 W
Number of digital inputs 8
Number of digital outputs 8
Number of analog inputs 4
Number of analog outputs 2
Reference potential for all digital inputs and
outputs
Minus pole of the supply voltage, signal name
ZP
