Technical Data
The System Data of AC500-eCo apply
Ä
Chapter 2.5.1 “System Data AC500-eCo”
on page 1192
Only additional details are therefore documented below.
Parameter Value
Galvanic isolation Yes, between the input groups and the rest of
the module
Isolated groups 2 (8 channels per group)
Current consumption from 24 V DC power
supply at the L+/UP and M/ZP terminals of the
CPU/bus module
Ca. 10 mA
Max. power dissipation within the module 6 W
Weight Ca. 222 g
Mounting position Horizontal or vertical
Cooling The natural convection cooling must not be
hindered by cable ducts or other parts in the
switch-gear cabinet.
Technical Data of the Digital Inputs
Parameter Value
Number of channels per module 16 AC inputs (100-240 VAC)
Distribution of the channels into groups 2 (8 channels per group)
Input voltage range 0 VAC...264 VAC (47 Hz...63 Hz)
Input current per channel (typically at 25 °C) < 3 mA (at 40 VAC)
> 6 mA (at 164 VAC)
> 8 mA (at 240 VAC)
Connections of the channels I0..I7 Terminals 1...8
Connections of the channels I8...I15 Terminals 10...17
Reference potential for the channels I0...I7 Terminal 9
Reference potential for the channels I8...I15 Terminal 18
Indication of the input signals 1 yellow LED per channel. The LED is on
when the input signal is high (signal 1).
Input type according to EN 61131-2 Type 1
Input signal range
Signal 0 (max.) 40 VAC
Undefined signal 40 VAC < U < 79 VAC
Signal 1 (min.) 79 VAC
Input delay
Signal 0 -> 1 Typ. 24 ms
Signal 1 -> 0 Typ. 24 ms
Input data length 2 bytes
I/O Modules > Digital I/O Modules
2019/04/17 3ADR010121, 13, en_US 221
