CTS Clear To Send
DCD Data Carrier Detect
DTR Data Terminal Ready
DSR Data Set Ready
FE Functional Earth
RI Ring Indicator
RTS Request To Send
RxD Receive Data
SGND Signal Ground
TxD Transmit Data
The TK502 cable connects a 9-pole serial COM interface of a PC with the serial COM1 interface
of PM57x, PM58x and PM59x. It is used for programming purposes.
With AC500/AC500-eCo processor modules, only the ABB programming cables
TK50x can be used. Other cables may cause communication faults and must
not be used.
The 2 plugs are put on the two COM interfaces and the plug at the PC side is tightened then.
Parameter Value
Connector at the PC (COM interface) D-sub, 9-pole, female
Connector at the AC500 CPU (COM1) terminal block, 9-pole, female
Cable length 5 m
Cable type LiYCY 5 x 0.14 mm², shielded
Weight 220 g
Part No. Description Product Life Cycle Phase *)
1SAP 180 200 R0101 TK502, programming cable
terminal block / D-sub, length:
5 m
Classic
*) For planning and commissioning of new installations use modules in Active
status only.
1.8.2.9 TK503 - Programming Cable
● PC-side: USB connector type A
● AC500-side: D-sub, 9-pin, male
● Length 3 m
TK503 programming cable connects the USB interface of a PC with the serial interface of a pro-
cessor module. It is used for programming purposes. TK503 can be used with all AC500 pro-
cessor modules.
Purpose
Electrical Con-
nection
Technical Data
Ordering Data
Intended Pur-
pose
Accessories > AC500 (Standard)
2019/04/17 3ADR010121, 13, en_US 1161
