ABB AC500 PLC - 1.7.5.2.7 Parameterization; Parameters of the Module

Details about configuration are described in Parameterization.
1.7.5.2.7 Parameterization
Parameters of the Module
Name Value Internal value Internal value,
type
Default
Module ID
1
)
Internal 0x1C25 WORD 0x1C25
Parameter length Internal 31 BYTE 31
Reserved (1
byte)
0 0 BYTE 0
Error LED / Fail-
safe function
Ä Table 162 “Set
tings "Error LED /
Failsafe func-
tion"”
on page 991
(see table )
On 0 BYTE 0
Off by E4 1
Off by E3 2
On + failsafe 16
Off by E4 + fail-
safe
17
Off by E3 + fail-
safe
18
Reserved (20
bytes)
0 0 BYTE 0
Check supply On 0 BYTE
Off 1 1
Fast counter 0 0 BYTE 0
: :
10
2
)
10
1
) With a faulty ID, the module reports a "parameter error" and does not perform cyclic process
data transmission.
2
) Counter operating modes, see Fast Counter Ä Chapter 1.5.1.2.10 “Fast Counter”
on page 394.
Table 162: Settings "Error LED / Failsafe function"
Setting Description
On Error LED (S-ERR) lights up at errors of all
error classes, Failsafe mode off
Off by E4 Error LED (S-ERR) lights up at errors of error
classes E1, E2 and E3, Failsafe mode off
Off by E3 Error LED (S-ERR) lights up at errors of error
classes E1 and E2, Failsafe mode off
On + Failsafe Error LED (S-ERR) lights up at errors of all
error classes, Failsafe mode on *)
Off by E4 + Failsafe Error LED (S-ERR) lights up at errors of error
classes E1, E2 and E3, Failsafe mode on *)
Off by E3 + Failsafe Error LED (S-ERR) lights up at errors of error
classes E1 and E2, Failsafe mode on *)
*) The parameter Behaviour DO at comm. error is only analyzed if the Failsafe mode is ON.
