Electromagnetic Compatibility
Test voltage 3V zone B, 10 V is also met.
High energy surges According to IEC 61000-4-5, zone B,
criterion B
Power supply DC 1 kV CM / 0.5 kV DM ²)
DC I/O supply 0.5 kV CM / 0.5 kV DM ²)
Communication Lines, shielded 1 kV CM ²)
AC I/O unshielded 2 kV CM / 1 kV DM ²)
I/O analog, I/O DC unshielded 1 kV CM / 0.5 kV DM ²)
Radiation (radio disturbance) According to IEC 55011, group 1, class
A
1
) High requirement for shipping classes are achieved with additional specific measures (see
specific documentation).
²) CM = Common Mode, DM = Differential Mode
2.6.1.6 Mechanical Data
Parameter Value
Mounting Horizontal
Degree of protection IP 20
Housing Classification V-2 according to UL 94
Vibration resistance acc. to EN 61131-2 all three axes
2 Hz...8.4 Hz, continuous 3.5 mm
8.4 Hz...150 Hz, continuous 1 g (higher values
on request)
Shock test All three axes
15 g, 11 ms, half-sinusoidal
Mounting of the modules:
DIN rail according to DIN EN 50022 35 mm, depth 7.5 mm or 15 mm
Mounting with screws Screws with a diameter of 4 mm
Fastening torque 1.2 Nm
2.6.1.7 Approvals and certifications
Information on approvals and certificates can be found in the corresponding chapter of the
Main catalog, PLC Automation.
2.6.2 Mechanical Dimensions
2.6.2.1 Switchgear Cabinet Assembly
Information on EMC-conforming assembly and construction is provided within
the overall functions section
Ä
Chapter 2.4.4 “EMC-Conforming Assembly and
Construction” on page 1186.
System Assembly, Construction and Connection
AC500 (Standard) > Mechanical Dimensions
2019/04/173ADR010121, 13, en_US1252
